Skinner Innovation PRO
Tattoo machine manual

Tattoo machine manual

Skinner Innovation PRO - wireless tattoo machine with color display and brushless motor

Here is a new generation of tattoo machines with a color display

and unique capabilities!

Features:
  • Bright and informative color display.
  • 5.6 watt brushless motor for low noise and vibration. This motor provides longer and more reliable operation with minimal energy consumption.
  • Common 18500 size battery with increased starting current. The battery life under average load reaches 6-7 hours. This time is enough for one full session.
  • Three memory cells that store the selected voltage and selected mode.
  • Holder: 32mm thread compatible with Cheyenne disposable holders.
  • The machine has a BASE mode that maintains speed, despite the load of the needle, which allows a professional master to work faster in one pass.
  • The machine has an adaptive ADAPT mode, where the power and frequency of the needle strike reacts to the surface tension of the skin, reduces the speed at the moment and prevents injury to the skin.
  • The session timer has a memory chip and you can save the session time even after changing the battery.
  • Service with a 12 month guarantee from the date of purchase.

Additional motor characteristics:
  • •5.6 watt brushless motor
  • 10800 rpm
  • 13 volts
  • 187 grams per cm torque.
  • 3700 rpm. / 5 volts
  • 5600 rpm / 7 volts
  • 7200 rpm/9 volts
  • 9000 rpm/11 volts
  • 10800 rpm/13 volts

Tattoo machine characteristics:
  • Voltage: 5-13 volts
  • Battery capacity: 1800 mAh
  • Operating time: more than 6-7 hours
  • LxWxH: 33x33x133 mm
  • Weight: 200 g
  • Needle stroke 3.8 mm and 4.5 mm


  • Double click on the Start button – switching memory cell
  • Single short press on the start button to start/stop the motor
  • Simultaneously pressing the Start and Plus buttons – switching BASE/ADAPT modes
  • Simultaneously pressing the Plus and Minus buttons resets the session timer
  • Long press on the Start button - ON/OFF the machine
Equipment:

Skinner Innovation machine, 2 removable batteries size 18500, charger with USB cable for two batteries, a pair of spare O-rings, QR code with instructions, durable box, warranty on the package.

Attention:

The batteries do not support fast charging/ultra-fast charging.
We recommend using a standard charger and cable. Fast charging/ultra-fast charging may damage the battery. We recommend charging batteries using a 2A adapter.
It is also not recommended to store batteries in the charging compartment.
We do not recommend storing the battery in a machine during transportation.

Working with the machine

  • Unscrew the cap counterclockwise, insert the battery with the negative contact facing you, screw the cap until it stops. The negative contact is the flat, completely even edge of the battery.
  • Press the middle large button to turn the machine on/off.
  • Quickly press the middle large button to pause the machine.
  • Press the large button twice to switch the memory location.
  • To reset the time on the timer, hold the top and bottom buttons for a couple of seconds.
  • To turn on/off adaptive mode, hold the top and middle buttons for a couple of seconds.

Caring for the machine

  • Disinfection of the holder should be carried out using disposable gloves. Turn off the machine before changing the cartridge.
  • The cartridge holder is autoclavable.
  • Repairs are provided free of charge under the warranty.
  • Machines cannot be sterilized in an autoclave or dry-heat oven!

Security measures

  • The machine is intended for professional use by tattoo artists only. The manufacturer is not responsible for improper operation of the equipment and its parts! And also for failure to comply with sterilization and disinfection standards.
  • Disposable cartridges must be used. Wipe the machine with a disinfectant before and after use.
  • Be sure to use barrier protection for the machine
  • Always use disposable gloves during the session.
  • If the device is not used for more than three days, it is recommended to remove the batteries.

Warranty does not apply:
  • Machine after an aggressive non-alcohol antiseptics;
  • The warranty on the battery applies for the first 2 weeks after purchase, strictly for the elimination of manufacturing defects.
  • Machine with signs of a fall, blows to the body and components;
  • With signs of independent reconfiguration and modernization;
  • If foreign bodies, liquids, or dirt get inside the mechanism
  • Operated for purposes other than intended;
  • Machine sterilized in an autoclave or dry-heat oven.
